local cfg = UI.Schema({
  enabled = UI.Toggle(true, {
    label = "Apply transforms",
    group = "Pointer Lab",
    tooltip = "Turn off to pass original movement through. The toggle key flips this setting.",
  }),
  toggle = UI.Keybind("F8", {
    label = "Toggle key",
    group = "Pointer Lab",
  }),
  invert_x = UI.Toggle(false, {
    label = "Invert horizontal input",
    group = "Direction",
    tooltip = "Reverse the mouse X axis before rotation.",
  }),
  invert_y = UI.Toggle(false, {
    label = "Invert vertical input",
    group = "Direction",
    tooltip = "Reverse the mouse Y axis before rotation.",
  }),
  rotation = UI.Slider(0, {
    label = "Rotation (clockwise)",
    group = "Direction",
    min = -180,
    max = 180,
    step = 1,
    suffix = "°",
    tooltip = "With inversion off, +90 degrees turns rightward input downward.",
  }),
  sensitivity_x = UI.Slider(1, {
    label = "Horizontal sensitivity",
    group = "Sensitivity",
    min = 0.1,
    max = 4,
    step = 0.05,
    suffix = "x",
    tooltip = "Scale the output X axis after rotation. 1x leaves it unchanged.",
  }),
  sensitivity_y = UI.Slider(1, {
    label = "Vertical sensitivity",
    group = "Sensitivity",
    min = 0.1,
    max = 4,
    step = 0.05,
    suffix = "x",
    tooltip = "Scale the output Y axis after rotation. 1x leaves it unchanged.",
  }),
  curve_enabled = UI.Toggle(false, {
    label = "Use a movement curve",
    group = "Movement curve",
    tooltip = "Vary gain with movement speed. Off keeps sensitivity constant.",
  }),
  curve = UI.Select("Smooth", { "Linear", "Smooth", "Quadratic" }, {
    label = "Curve shape",
    group = "Movement curve",
    showIf = "curve_enabled",
    tooltip = "Linear changes evenly. Smooth eases at both ends. Quadratic changes slowly at first.",
  }),
  slow_gain = UI.Slider(0.5, {
    label = "Slow movement gain",
    group = "Movement curve",
    showIf = "curve_enabled",
    min = 0.1,
    max = 3,
    step = 0.05,
    suffix = "x",
    tooltip = "Gain near rest, multiplied by each axis sensitivity.",
  }),
  fast_gain = UI.Slider(2, {
    label = "Fast movement gain",
    group = "Movement curve",
    showIf = "curve_enabled",
    min = 0.1,
    max = 3,
    step = 0.05,
    suffix = "x",
    tooltip = "Gain at and above the transition speed. Set below slow gain to decelerate.",
  }),
  transition_speed = UI.Slider(10, {
    label = "Transition speed",
    group = "Movement curve",
    showIf = "curve_enabled",
    min = 0.5,
    max = 50,
    step = 0.5,
    suffix = " counts/ms",
    tooltip = "Raw movement speed at which fast gain is reached. Mouse DPI affects this value.",
  }),
})

local pending_x, pending_y = 0, 0
local remainder_x, remainder_y = 0, 0

local function reset_motion()
  pending_x, pending_y = 0, 0
  remainder_x, remainder_y = 0, 0
end

-- saved UI values are not range-checked by the SDK.
local function number_setting(value, default, low, high)
  if type(value) ~= "number" or value ~= value then
    return default
  end
  return math.max(low, math.min(high, value))
end

Bind(cfg.toggle, function()
  cfg.enabled = not cfg.enabled
  reset_motion()
  UI.Notify(cfg.enabled and "Pointer Lab enabled." or "Pointer Lab bypassed.")
end)

function OnMove(dx, dy)
  if cfg.enabled ~= true then
    reset_motion()
    return true
  end
  -- combine separately delivered X/Y events before measuring speed or rotating.
  pending_x = pending_x + dx
  pending_y = pending_y + dy
  return false
end

function OnTick(dt_ms)
  if cfg.enabled ~= true then
    reset_motion()
    return
  end
  local dx, dy = pending_x, pending_y
  pending_x, pending_y = 0, 0
  if dx == 0 and dy == 0 then
    return
  end

  local gain = 1
  if cfg.curve_enabled == true then
    local elapsed = dt_ms > 0 and dt_ms or 1
    local speed = math.sqrt(dx * dx + dy * dy) / elapsed
    local transition = number_setting(cfg.transition_speed, 10, 0.5, 50)
    local t = math.min(speed / transition, 1)
    if cfg.curve == "Smooth" then
      t = t * t * (3 - 2 * t)
    elseif cfg.curve == "Quadratic" then
      t = t * t
    end
    local slow = number_setting(cfg.slow_gain, 0.5, 0.1, 3)
    local fast = number_setting(cfg.fast_gain, 2, 0.1, 3)
    gain = slow + (fast - slow) * t
  end

  if cfg.invert_x == true then
    dx = -dx
  end
  if cfg.invert_y == true then
    dy = -dy
  end
  local angle = math.rad(number_setting(cfg.rotation, 0, -180, 180))
  local c, s = math.cos(angle), math.sin(angle)
  local x = (dx * c - dy * s)
      * number_setting(cfg.sensitivity_x, 1, 0.1, 4)
      * gain
    + remainder_x
  local y = (dx * s + dy * c)
      * number_setting(cfg.sensitivity_y, 1, 0.1, 4)
      * gain
    + remainder_y
  local out_x, out_y = math.floor(x + 0.5), math.floor(y + 0.5)
  -- HID.Move accepts integers; carry fractions instead of losing slow movement.
  remainder_x, remainder_y = x - out_x, y - out_y
  if out_x ~= 0 or out_y ~= 0 then
    HID.Move(out_x, out_y)
  end
end

function OnStop()
  reset_motion()
end

function OnBlur()
  reset_motion()
end
