Controller Map

A live controller tester for Rebind.

Controller Map shows every controller button and axis Rebind receives, using the same names scripts use. It is useful for checking a controller, verifying a Rebind Link setup, or learning which input maps to which name.

What it does

Detects a connected gamepad or joystick.
Shows pressed buttons as highlighted keycaps.
Shows the raw Rebind name beside each button.
Shows live stick and trigger axes with values and bars.
Updates continuously without taking focus.
Can be shown or hidden with one hotkey.
No input blocking, no recording, no network.

Quick start

Install and start Controller Map.
Connect a controller through Rebind Link in hardware mode.
Press Ctrl+Alt+G to show the HUD.
Press buttons and move the sticks to test them.
Press Ctrl+Alt+G again to hide it.

Controls

Key	Action
Ctrl+Alt+G	Show or hide the controller map.

The hotkey is configurable.

Settings

Show on start
Show buttons
Show axes
Position — top-left, top-right, bottom-left, or bottom-right.

Button names

Control	Rebind name
Face buttons	`PadA`, `PadB`, `PadX`, `PadY`
Bumpers	`PadLB`, `PadRB`
Triggers pressed	`PadLT`, `PadRT`
View / Menu	`PadView`, `PadMenu`
Stick clicks	`PadLS`, `PadRS`
D-pad	`PadUp`, `PadDown`, `PadLeft`, `PadRight`
Paddles	`PadP1` to `PadP4`

Buttons are named by position, using Xbox letters, so PadA is the bottom face button on any controller.

Axis names

Axis	Range
`LeftX`, `LeftY`	-1 to 1; up and left are negative
`RightX`, `RightY`	-1 to 1
`LT`, `RT`	0 to 1

Limits

Controllers are captured only in hardware mode.
Rebind Link's joypad is a standard HID gamepad, not an Xbox controller. Games that read only XInput may not see it.
Rumble, motion sensors, and touch position are not shown.
Several controllers share one Rebind joypad; this displays the combined state.
The overlay is click-through and cannot be clicked.
Rebind overlays do not appear over exclusive-fullscreen games.

Privacy

Controller Map only reads the live controller state Rebind exposes. It does not capture the screen, read the clipboard, use the network, or store input history.

Requirements

Rebind 3.12.0 or newer
Rebind Link with a USB profile that includes a joypad
A desktop where Rebind overlays are supported

Controller Map v1.0.0 — see what the controller is actually sending.

Version 1.0.0 (current)

main.luau

--[[
  rebind: min_sdk=3.12.0
  rebind: permissions=none
  rebind: tick_rate=30
  rebind: memory_limit_mb=16
]]

local COLORS = {
  panel = "#11100FF5",
  key = "#1A1917",
  key_active = "#8FB7FF20",
  border = "#2E2A26",
  border_active = "#8FB7FF90",
  text = "#F4F1E8",
  soft = "#D8DDD3",
  muted = "#A39C94",
  accent = "#8FB7FF",
  line = "#332D28",
}

local BUTTONS = {
  { id = "PadA", label = "A" },
  { id = "PadB", label = "B" },
  { id = "PadX", label = "X" },
  { id = "PadY", label = "Y" },
  { id = "PadLB", label = "LB" },
  { id = "PadRB", label = "RB" },
  { id = "PadLT", label = "LT" },
  { id = "PadRT", label = "RT" },
  { id = "PadView", label = "VIEW" },
  { id = "PadMenu", label = "MENU" },
  { id = "PadLS", label = "LS" },
  { id = "PadRS", label = "RS" },
  { id = "PadUp", label = "UP" },
  { id = "PadDown", label = "DOWN" },
  { id = "PadLeft", label = "LEFT" },
  { id = "PadRight", label = "RIGHT" },
}

local AXES = {
  { id = "LeftX", label = "LX", signed = true },
  { id = "LeftY", label = "LY", signed = true },
  { id = "RightX", label = "RX", signed = true },
  { id = "RightY", label = "RY", signed = true },
  { id = "LT", label = "LT", signed = false },
  { id = "RT", label = "RT", signed = false },
}

local cfg = rb.ui.schema({
  toggle_key = rb.ui.keybind("Ctrl+Alt+G", {
    label = "Show / hide controller",
    group = "Hotkeys",
  }),
  show_on_start = rb.ui.toggle(false, {
    label = "Show on start",
    group = "Behavior",
  }),
  show_buttons = rb.ui.toggle(true, {
    label = "Show buttons",
    group = "Display",
  }),
  show_axes = rb.ui.toggle(true, {
    label = "Show axes",
    group = "Display",
  }),
  anchor = rb.ui.select("bottom-right", {
    "top-left",
    "top-right",
    "bottom-left",
    "bottom-right",
  }, {
    label = "Position",
    group = "Display",
  }),
})

local state = {
  visible = cfg.show_on_start ~= false,
  surface = nil,
  signature = nil,
}

local function add_rect(ops, x, y, width, height, fill, radius, border, border_width)
  local op = {
    kind = "rect",
    x = x,
    y = y,
    w = width,
    h = height,
    fill = fill,
    radius = radius or 0,
  }
  if border then
    op.border = border
    op.border_width = border_width or 1
  end
  ops[#ops + 1] = op
end

local function add_text(ops, x, y, size, value, color, bold)
  ops[#ops + 1] = {
    kind = "text",
    x = x,
    y = y,
    size = size,
    text = value,
    color = color,
    bold = bold == true,
  }
end

local function text_width(value, size, bold)
  local ok, width = pcall(rb.overlay.measure, value, size, bold)
  if ok and width then
    return width
  end
  return #value * size * 0.62
end

local function controller_device()
  local ok, devices = pcall(rb.input.devices)
  if not ok or type(devices) ~= "table" then
    return nil
  end
  for _, device in ipairs(devices) do
    if device.kind == "gamepad" or device.kind == "joystick" then
      return device
    end
  end
  return nil
end

local function is_down(id)
  local ok, value = pcall(rb.input.is_down, id)
  return ok and value == true
end

local function axis_value(id)
  local ok, value = pcall(rb.input.axis, id)
  if ok and type(value) == "number" then
    return value
  end
  return 0
end

local function remove_surface()
  if state.surface then
    pcall(function()
      state.surface:remove()
    end)
    state.surface = nil
  end
end

local function device_label(device)
  if not device then
    return "NO CONTROLLER DETECTED"
  end
  local name = device.nickname or device.name or "Controller"
  return string.upper(tostring(name))
end

local function draw()
  if not state.visible then
    remove_surface()
    return
  end

  local device = controller_device()
  local button_states = {}
  local axis_states = {}
  local signature_parts = {
    tostring(cfg.anchor),
    tostring(cfg.show_buttons),
    tostring(cfg.show_axes),
    device_label(device),
  }

  for _, button in ipairs(BUTTONS) do
    button_states[button.id] = is_down(button.id)
    signature_parts[#signature_parts + 1] = button.id .. "=" .. tostring(button_states[button.id])
  end
  for _, axis in ipairs(AXES) do
    local value = axis_value(axis.id)
    axis_states[axis.id] = value
    signature_parts[#signature_parts + 1] = axis.id .. "=" .. string.format("%.2f", value)
  end

  local signature = table.concat(signature_parts, "|")
  if signature == state.signature then
    return
  end
  state.signature = signature

  local width = 560
  local show_buttons = cfg.show_buttons ~= false
  local show_axes = cfg.show_axes ~= false
  local height = 78
  if show_buttons then
    height = height + 30 + 4 * 36
  end
  if show_axes then
    height = height + 30 + #AXES * 28
  end
  height = height + 16

  local ops = {}
  add_rect(ops, 0, 0, width, height, COLORS.panel, 16, COLORS.line, 1)
  add_rect(ops, 22, 22, 3, 30, COLORS.accent, 1)
  add_text(ops, 36, 18, 18, "CONTROLLER", COLORS.text, true)
  add_text(ops, 36, 43, 10, device_label(device), COLORS.muted)
  add_text(ops, width - 24 - text_width("Ctrl+Alt+G", 9, false), 22, 9, "Ctrl+Alt+G", COLORS.muted)

  local y = 78
  if show_buttons then
    add_text(ops, 22, y, 9, "BUTTONS", COLORS.muted, true)
    y = y + 30
    for index, button in ipairs(BUTTONS) do
      local column = (index - 1) % 4
      local row = (index - 1) // 4
      local x = 16 + column * 132
      local row_y = y + row * 36
      local pressed = button_states[button.id] == true
      add_rect(
        ops,
        x,
        row_y,
        124,
        28,
        pressed and COLORS.key_active or COLORS.key,
        7,
        pressed and COLORS.border_active or COLORS.border,
        1
      )
      add_text(ops, x + 10, row_y + 8, 10, button.label, pressed and COLORS.text or COLORS.soft, true)
      add_text(
        ops,
        x + 124 - 10 - text_width(button.id, 8, false),
        row_y + 9,
        8,
        button.id,
        COLORS.muted
      )
    end
    y = y + 4 * 36
  end

  if show_axes then
    add_text(ops, 22, y, 9, "AXES", COLORS.muted, true)
    y = y + 30
    for _, axis in ipairs(AXES) do
      local value = axis_states[axis.id] or 0
      local bar_x = 70
      local bar_width = 360
      local bar_y = y + 7
      add_text(ops, 22, y + 6, 9, axis.label, COLORS.soft, true)
      add_rect(ops, bar_x, bar_y, bar_width, 7, "#252A2E", 3)
      if axis.signed then
        local center = bar_x + bar_width / 2
        local amount = math.min(1, math.abs(value)) * (bar_width / 2)
        if value >= 0 then
          add_rect(ops, center, bar_y, math.max(1, amount), 7, COLORS.accent, 3)
        else
          add_rect(ops, center - amount, bar_y, math.max(1, amount), 7, COLORS.accent, 3)
        end
      elseif value > 0 then
        add_rect(ops, bar_x, bar_y, math.max(1, bar_width * math.min(1, value)), 7, COLORS.accent, 3)
      end
      add_text(
        ops,
        bar_x + bar_width + 18,
        y + 5,
        9,
        string.format("%.2f", value),
        COLORS.muted
      )
      y = y + 28
    end
  end

  if not device then
    add_text(ops, 22, height - 22, 9, "Connect a controller in hardware mode to see live input.", COLORS.muted)
  end

  if state.surface then
    local ok = pcall(function()
      state.surface:set({
        width = width,
        height = height,
        ops = ops,
      })
    end)
    if not ok then
      remove_surface()
    end
  end

  if not state.surface then
    local ok, surface = pcall(rb.overlay.surface, {
      anchor = cfg.anchor,
      width = width,
      height = height,
      ops = ops,
    })
    if ok then
      state.surface = surface
    else
      rb.log.warn("Controller Map: could not create surface: " .. tostring(surface))
    end
  end
end

local function toggle()
  state.visible = not state.visible
  state.signature = nil
  if state.visible then
    draw()
  else
    remove_surface()
  end
end

local function tick()
  if state.visible then
    draw()
  end
end

rb.bind(cfg.toggle_key, toggle)

function OnStart()
  state.visible = cfg.show_on_start ~= false
  state.signature = nil
  draw()
end

function OnTick()
  tick()
end

function OnStop()
  remove_surface()
end
