Input Display

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324

--[[
  rebind: min_sdk=3.11.0
  rebind: permissions=none
  rebind: tick_rate=30
  rebind: memory_limit_mb=16
]]

local COLORS = {
  panel = "#0E110FF5",
  key = "#181D18",
  key_active = "#C7F36B18",
  border = "#2A332A",
  border_active = "#C7F36B70",
  text = "#F4F1E8",
  soft = "#D8DDD3",
  muted = "#98A398",
  accent = "#C7F36B",
}

local LABELS = {
  Mouse1 = "LMB",
  Mouse2 = "RMB",
  Mouse3 = "MMB",
  Mouse4 = "M4",
  Mouse5 = "M5",
  Space = "SPACE",
  Enter = "ENTER",
  Escape = "ESC",
  Backspace = "BACK",
  Tab = "TAB",
  LShift = "LSHIFT",
  RShift = "RSHIFT",
  LCtrl = "LCTRL",
  RCtrl = "RCTRL",
  LAlt = "LALT",
  RAlt = "RALT",
  LWin = "LWIN",
  RWin = "RWIN",
  PadA = "A",
  PadB = "B",
  PadX = "X",
  PadY = "Y",
  PadLB = "LB",
  PadRB = "RB",
  PadLT = "LT",
  PadRT = "RT",
  PadView = "VIEW",
  PadMenu = "MENU",
  PadLS = "LS",
  PadRS = "RS",
  PadUp = "UP",
  PadDown = "DOWN",
  PadLeft = "LEFT",
  PadRight = "RIGHT",
}

local PRIORITY = {
  Mouse1 = 1,
  Mouse2 = 2,
  Mouse3 = 3,
  Mouse4 = 4,
  Mouse5 = 5,
  W = 10,
  A = 11,
  S = 12,
  D = 13,
  Space = 14,
  LShift = 15,
  RShift = 16,
  LCtrl = 17,
  RCtrl = 18,
  LAlt = 19,
  RAlt = 20,
  Tab = 21,
  Enter = 22,
  Escape = 23,
}

local cfg = rb.ui.schema({
  toggle_key = rb.ui.keybind("Ctrl+Alt+I", {
    label = "Show / hide display",
    group = "Hotkeys",
  }),
  show_on_start = rb.ui.toggle(false, {
    label = "Show on start",
    group = "Behavior",
  }),
  show_mouse = rb.ui.toggle(true, {
    label = "Show mouse buttons",
    group = "Behavior",
  }),
  show_controller = rb.ui.toggle(true, {
    label = "Show controller buttons",
    group = "Behavior",
  }),
  max_keys = rb.ui.slider(8, {
    min = 4,
    max = 16,
    step = 1,
    label = "Maximum keys shown",
    group = "Display",
  }),
  anchor = rb.ui.select("bottom-left", {
    "top-left",
    "top-right",
    "bottom-left",
    "bottom-right",
  }, {
    label = "Position",
    group = "Display",
  }),
})

local state = {
  visible = cfg.show_on_start ~= false,
  surface = nil,
  signature = nil,
}

local function add_rect(ops, x, y, width, height, fill, radius, border, border_width)
  local op = {
    kind = "rect",
    x = x,
    y = y,
    w = width,
    h = height,
    fill = fill,
    radius = radius or 0,
  }
  if border then
    op.border = border
    op.border_width = border_width or 1
  end
  ops[#ops + 1] = op
end

local function add_text(ops, x, y, size, value, color, bold)
  ops[#ops + 1] = {
    kind = "text",
    x = x,
    y = y,
    size = size,
    text = value,
    color = color,
    bold = bold == true,
  }
end

local function text_width(value, size, bold)
  local ok, width = pcall(rb.overlay.measure, value, size, bold)
  if ok and width then
    return width
  end
  return #value * size * 0.62
end

local function key_label(key)
  local label = LABELS[key]
  if label then
    return label
  end
  if #key > 8 then
    return key:sub(1, 8)
  end
  return key
end

local function is_controller_key(key)
  return key:sub(1, 3) == "Pad" or key:sub(1, 3) == "Joy"
end

local function visible_keys()
  local keys = {}
  local held = rb.input.keys() or {}
  for _, key in ipairs(held) do
    local show = true
    if not cfg.show_mouse and key:sub(1, 5) == "Mouse" then
      show = false
    end
    if not cfg.show_controller and is_controller_key(key) then
      show = false
    end
    if show then
      keys[#keys + 1] = key
    end
  end

  table.sort(keys, function(a, b)
    local pa = PRIORITY[a] or 50
    local pb = PRIORITY[b] or 50
    if pa == pb then
      return a < b
    end
    return pa < pb
  end)
  return keys
end

local function remove_surface()
  if state.surface then
    pcall(function()
      state.surface:remove()
    end)
    state.surface = nil
  end
end

local function draw(keys)
  if not state.visible then
    remove_surface()
    return
  end

  local limit = math.max(4, math.min(16, math.floor(tonumber(cfg.max_keys) or 8)))
  local shown = {}
  for index = 1, math.min(#keys, limit) do
    shown[#shown + 1] = keys[index]
  end
  local extra = math.max(0, #keys - limit)
  local rows = math.max(1, math.ceil(#shown / 4))
  local height = 62 + rows * 38 + (extra > 0 and 16 or 0)
  local signature = table.concat(shown, ",")
    .. "|" .. tostring(extra)
    .. "|" .. tostring(cfg.anchor)
    .. "|" .. tostring(limit)
  if signature == state.signature then
    return
  end
  state.signature = signature

  local ops = {}
  add_rect(ops, 0, 0, 360, height, COLORS.panel, 14, COLORS.border, 1)
  add_rect(ops, 16, 16, 3, 24, COLORS.accent, 1)
  add_text(ops, 28, 12, 11, "INPUT", COLORS.text, true)
  add_text(ops, 28, 30, 9, "LIVE", COLORS.muted)
  add_text(ops, 300, 12, 9, "Ctrl+Alt+I", COLORS.muted)

  if #shown == 0 then
    add_rect(ops, 16, 48, 328, 30, COLORS.key, 8, COLORS.border, 1)
    add_text(ops, 24, 56, 10, "Press any key", COLORS.muted)
  else
    for index, key in ipairs(shown) do
      local column = (index - 1) % 4
      local row = (index - 1) // 4
      local x = 16 + column * 84
      local y = 48 + row * 38
      local label = key_label(key)
      local label_width = text_width(label, 10, true)
      add_rect(ops, x, y, 76, 30, COLORS.key_active, 7, COLORS.border_active, 1)
      add_text(
        ops,
        x + (76 - label_width) / 2,
        y + 9,
        10,
        label,
        COLORS.text,
        true
      )
    end
    if extra > 0 then
      add_text(ops, 16, 54 + rows * 38, 9, "+" .. tostring(extra) .. " more", COLORS.muted)
    end
  end

  if state.surface then
    local ok = pcall(function()
      state.surface:set({
        width = 360,
        height = height,
        ops = ops,
      })
    end)
    if not ok then
      remove_surface()
    end
  end

  if not state.surface then
    local ok, surface = pcall(rb.overlay.surface, {
      anchor = cfg.anchor,
      width = 360,
      height = height,
      ops = ops,
    })
    if ok then
      state.surface = surface
    else
      rb.log.warn("Input Display: could not create surface: " .. tostring(surface))
    end
  end
end

local function toggle()
  state.visible = not state.visible
  state.signature = nil
  if state.visible then
    draw(visible_keys())
  else
    remove_surface()
  end
end

local function tick()
  if not state.visible then
    return
  end
  draw(visible_keys())
end

rb.bind(cfg.toggle_key, toggle)

function OnStart()
  state.visible = cfg.show_on_start ~= false
  state.signature = nil
  draw(visible_keys())
end

function OnTick()
  tick()
end

function OnStop()
  remove_surface()
end
